Parcel Sorting Systems for Warehouses and Logistics Hubs

Explore straight-line crossbelt, wheel and Z-type carrier sorters. We help you select a system around your parcel mix, peak-hour volume, available space and sorting destinations.

Get a sorting recommendation Compare sorting systems

Wheel sorter installation with multiple discharge lanes and integrated belt conveyors.

Straight-line crossbelt sorter

A straight-line sorting system for mixed bags and cartons. Parcels are routed to collection points by destination, courier or SKU, with the configuration matched to your workflow and available space.

Layout: Straight-line arrangement with side collection points.
Sorting rules: Destination, courier or SKU.
DWS integration: Discuss an upstream dynamic DWS configuration.

Discuss a straight-line sorter

Wheel sorter

Warehouse parcel sorting line with swivel-wheel modules, belt conveyors and side discharge lanes.

Route parcels to the right dispatch lane.

Swivel-wheel modules guide parcels into designated lanes based on barcode data and your sorting rules. Configure the system around your courier allocation, destination groups and warehouse workflow.

Layout that fits your operation: Arrange infeed conveyors, discharge lanes and collection areas around your available space and dispatch process.
A clear route for exceptions: Include a separate lane for unreadable barcodes and parcels that need manual review.
Optional DWS integration: Add upstream weighing and dimensioning when your workflow requires parcel weight and size data.

Discuss your sorting layout

Z-type carrier sorter

Modular sorting line with side discharge points in a bright factory — Modular sorting sections with side discharge points.

A compact, modular carrier sorting system for e-commerce warehouses and logistics hubs. It combines barcode scanning and parcel routing, with optional weighing and dimensioning configured for the project.

Layout: Compact, modular carrier system.
Chutes: Quantity configured for the project.
DWS integration: Optional weighing and dimensioning.

Discuss a Z-type sorter

Compare sorting systems

Compare the main configuration choices, then share your parcel and site requirements for a tailored recommendation.

Feature	Straight-line crossbelt sorter	Wheel sorter	Z-type carrier sorter
Sorting speed	7,500 PPH	3,500 PPH	1,000 PPH
Sorting accuracy	99.9%	99.9%	99.9%
System layout	Straight-line arrangement	Site-specific discharge layout	Compact modular carrier system
Sorting configuration	Destination, courier or SKU	Courier or destination routing	Project-specific chute allocation
Collection points	Side chutes or bins	Discharge lanes and exception lane	Chute count set per project
Weighing and dimensioning	Discuss dynamic DWS integration	Optional project configuration	Optional project configuration
Applications	E-commerce and warehouse outbound sorting	E-commerce, courier hubs, 3PL and retail distribution	E-commerce warehouses and logistics hubs

Sorter selection

Which sorting system fits?

The system follows the parcel mix, the peak hour and the building.

Send these details and NetRay will come back with a configuration, or say a sorter is not the right next step yet:

Daily parcel volume and peak-hour throughput
Parcel size, weight and packaging type — polybags, cartons, envelopes
How many sorting destinations
Floor space available
The WMS, ERP or courier system the line has to connect to
How sorting is handled today, and where it slows down

Prefer a message? Get a sorting recommendation on WhatsApp.
